CurvaLab DENTAL CAST Resin for LCD 3D printers is engineered for high‑precision dental casting applications, delivering clean burnout performance with zero ash residue. Its specialized formulation ensures sharp detailing, smooth surfaces, and excellent dimensional stability, making it ideal for crowns, bridges, dental frameworks, and laboratory‑grade casting models.
🦷 Key Features
• Clean burnout with no ash, ideal for lost‑wax dental casting.
• High‑detail resolution suitable for small and intricate dental structures.
• Excellent dimensional stability for accurate clinical reproduction.
• Smooth surface finish requiring minimal post‑processing.
• Low shrinkage ensures precise fit and reliable casting results.
• Compatible with LCD/MSLA.
🧩 Recommended Applications
• Dental casting models
• Crowns, bridges, and precision frameworks
• Laboratory molds and diagnostic replicas
• Small jewelry casting
• High‑accuracy dental demonstrations
🔧 Recommended Print Settings
•Layer height (mm): 0.05-0.1
•Bottom exposure time(s): 30-50
•Layer exposure time(s): 3-5
•Bottom Lift Distance (mm): 6
•Lifting Distance (mm): 6
•Bottom Lift Speed (mm/min): 60
•Lifting Speed (mm/min): 80
•Retract Speed (mm/min): 150
•Rest time after retract: 2-3
📊 Resin performance
• Tensile Strength: 20–35 MPa
• Flexural Strength: 25–45 MPa
• Elongation at Break: 5–12%
• Shore Hardness: 75 – 85
• Viscosity: 300 – 500 mPa·s
• Density: 1.05 – 1.20 g/cm³
• Shrinkage: Very low
💡 Pro Tips
• Shake the bottle thoroughly before printing.
• Use gloves and proper ventilation.
• Clean prints with IPA or a suitable cleaning solution.
• Dry completely before curing.
• Follow a controlled burnout schedule for optimal casting performance.
